Airtight Sealed Door for Cleanroom and Industrial Areas
7-in-1 protection——Airtight, soundproof, insulated, pressure-resistant, dustproof, fireproof & radiation-proof. DC brushless motor——Supports frequent operation without failure; Manual override during power failure. Vacuum sealing strips + p
- Information
Airtight Sealed Door Applications and Related Door Solutions
Airtight Sealed Door supports demanding industrial and public-building applications where safety, durability, sealing, and stable daily operation are important.
Related Products: Apartment Door | Steel Single-leaf Soundproof Door | Steel Soundproof Sliding Door
JIAHUI DOOR
Airtight Sealed Door—Industry
Product Features
Multi-Purpose Protection
The airtight sliding door integrates seven critical functions: airtight sealing (pressure differential ≤5Pa), 35dB sound insulation, thermal insulation, 1200Pa pressure resistance, ISO Class 5 dust prevention, fire resistance (rating configurable), and radiation shielding.
Reliable Drive System
Equipped with a 180W DC brushless motor (AC220V/50Hz)
100,000+ operation cycles verified
Emergency manual handle requires ≤20N force during outages
Airtight Engineering
Professional vacuum sealing strips on all four edges
Compression technology ensures ≤0.5mm gap closure
7.3m perimeter sealing length
Intelligent Controls
| Feature | Specification |
|---|---|
| Opening Speed | 30-1500 mm/sec adjustable |
| Sensors | Hands-free infrared + foot pedal |
| Remote Control | 10m operating range |
| Safety | Obstruction detection auto-stop |
Customizable Design
| Parameter | Standard | Custom |
|---|---|---|
| Opening Size | 1.4m(W)×2.24m(H) | 0.9-2.0m(W)×1.8-2.5m(H) |
| Weight | 70kg | <100kg |
| Surface | Medical-grade smooth finish | 12+ RAL colors |
Product Advantages
Certified Hospital Safety
Meets "Clean Hospital Guidelines"
ISO 14644-1 Cleanroom Compliance
Non-porous surfaces prevent bacterial growth
Operational Efficiency
30% faster throughput vs traditional doors
Dual-mode operation (auto/manual) ensures uninterrupted access
Low Total Ownership
Corrosion-resistant aluminum alloy frame
Annual maintenance reduces to 1-2 checkups
Motor lifespan exceeds 8 years
Adaptable Integration
Compatible with building management systems
Sensor behaviors programmable for workflow optimization (e.g. surgery schedules)
Application Range
Medical Facilities
Operating theaters (ISO Class 5+ environments)
Radiology/CT screening rooms
Pharmaceutical cleanrooms
Isolation wards & bio-labs
Critical Environments
| Sector | Application | Key Benefit |
|---|---|---|
| Laboratories | Animal research zones | Cross-contamination prevention |
| Electronics | Microchip production | Particle control <0.3μm |
| Food | Packaging cleanrooms | HACCP compliance |
| Industrial | Battery manufacturing | Explosion-proof safety |
Architectural Compliance
Installs in concrete/steel partitions (200mm+ thickness)
Adapts to negative/positive pressure rooms
CE-marked mechanical components
