Double Leaf Blast Resistant Door for Industrial Safety

Double-Leaf Blast-Resistant Door Applications and Related Door Solutions

Double-Leaf Blast-Resistant Door supports demanding industrial and public-building applications where safety, durability, sealing, and stable daily operation are important.

Related Products: Apartment Door | Steel Single-leaf Soundproof Door | Steel Soundproof Sliding Door

JIAHUI  DOOR

Double-Leaf Blast-Resistant Door—Industrial door

Product Features

Our double-leaf explosion-proof door is engineered for maximum protection in hazardous environments. The 70mm-thick door leaf consists of 1.5mm galvanized steel panels on both sides, reinforced with a steel skeleton and honeycomb paper/insulation cotton filling for optimal strength-to-weight ratio. The 180mm-wide door frame is constructed from 2.0mm galvanized cold-rolled steel, featuring an integrated single-seal gasket to prevent gas/dust infiltration.

Key structural elements include:

• Over 50% thick steel pipe reinforcement inside the door leaf.

• 1.0mm galvanized steel outer panels for corrosion resistance.

• Explosion-proof lock system for enhanced security.

Key Advantages

✔ Unmatched Blast Resistance – Withstands ≥69Kpa shockwave pressure, making it ideal for chemical plants, military bunkers, and oil refineries.
✔ Precision Manufacturing – Flatness ≤4mm/m² and tight dimensional tolerances ensure seamless installation.
✔ Durable & Lightweight – Honeycomb paper & insulation cotton filling reduces weight while maintaining structural integrity.
✔ Airtight Protection – Single-seal gasket in the frame prevents hazardous gas leaks.

Applications

These double-leaf blast doors are essential for:

• Oil & Gas Facilities – Secure control rooms & hazardous storage.

• Military & Defense – Protect ammunition depots & command centers.

• Chemical Plants – Isolate explosion-prone zones.

• Power Stations – Shield critical infrastructure.

Technical Specifications

• Door Leaf Thickness: 70mm

• Door Leaf Steel Thickness: 1.5mm (galvanized)

• Door Frame Width: 180mm

• Door Frame Steel Thickness: 2.0mm (galvanized)

• Filling Material: Honeycomb paper / Insulation cotton

• Sealing System: Single airtight gasket

• Lock Type: Explosion-proof lock

• Blast Resistance: ≥69Kpa

• Flatness Tolerance: ≤4mm/m²

• Dimensional Tolerances:

• <1000mm: ≤2mm

• 2000mm: ≤3mm

• 2000-3500mm: ≤4mm

• >3500mm: ≤5mm

---

Standard Configuration

Specification Item	Technical Details
Door Leaf Thickness	70mm
Door Leaf Steel Thickness	1.5mm Galvanized Steel
Door Frame Width	180mm
Door Frame Steel Thickness	2.0mm Galvanized Steel
Filling Material	Honeycomb Paper/Insulation Wool
Sealing Groove	Single Air-Tight Seal Channel
Locking System	Explosion-Proof Lock
